INTEL MB DH55PJ/IBEX PEAK/iH55 LGA1156/mATX/A8ch,GLAN,DDR3 - Bulk

Form factor microATX

Processor:
Intel® Core™ i7 processors in an LGA1156 socket
Intel® Core™ i5 processors in an LGA1156 socket
Intel® Core™ i3 processors in an LGA1156 socket
Intel® Pentium® processors in an LGA1156 socket

Memory:
2x 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
Support for DDR3 1333 /1066 MHz DIMMs
Support for up to 8 GB of system memory

Chipset Intel® H55 Express Chipset

Audio Intel® High Definition Audio? subsystem in the following configuration:
8-channel (5.1+ 2 independent multi-streaming) audio subsystem with three analog audio outputs using the Realtek* ALC888S audio codec

LAN support: Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel® 82578DC Gigabit Ethernet Controller
Peripheral interfaces Up to twelve USB 2.0 ports
4x Serial ATA 3.0 Gb/s ports
1x serial port header
1x parallel port header
1x back panel PS/2 connector

Expansion capabilities:
1x PCI Express* 2.0 x 16 bus add-in card connector
2x PCI Express 2.0 x 1 connectors
1x PCI Conventional bus connector
