Thecus V6810 Kamerové Datové úložiště - 6 pozic HDD,Intel® Core™ i3-2120 , 4GB DDR3 , USB 2.0 x 4 , USB 3.0 x 4 , HDMI


Thecus V6810 Kamerové Datové úložiště - 6 pozic HDD,Intel® Core™ i3-2120 , 4GB DDR3 , USB 2.0 x 4 , USB 3.0 x 4 , HDMI

Item Spec; Processor Intel® Core™ i3-2120; System Memory 4GB DDR3; LAN Interface (PCI-e) RJ-45x2: Intel 82574L 10/100/1000 BASE-TX Auto MDI/MDI-X; WOL supported; USB Interface USB 2.0 host port x4 (front x2, back x2) (Type A); USB 3.0 host port x4 (fro...Více info

Kód
PV133686
Part No.
V6810
Výrobce
Thecus
Záruka
24 Měsíce
Dostupnost
Koncová cena bez DPH + RP
26 796 Kč
Vaše cena bez DPH a poplatků
26 796 Kč
DPH
21%
Vaše cena s DPH (21%)
32 423 Kč

    Základní informace


    Item  Spec
    Processor Intel® Core™ i3-2120
    System Memory 4GB DDR3
    LAN Interface (PCI-e) RJ-45x2: Intel 82574L 10/100/1000 BASE-TX Auto MDI/MDI-X
    WOL supported
    USB Interface USB 2.0 host port x4 (front x2, back x2) (Type A)
    USB 3.0 host port x4 (front x2, back x2)
    OLED Displays system status and information (Multilingual)
    HDMI Output HDMI port (back x1)
    Audio MIC input, Line input, Audio output
    Disk Interface 6 x SATA for internal
    Power Supply Single Power Supply
    System Clock Battery-backed up system clock
    Power Management Auto power on after shutdown due to power loss
    Buzzer Adjustable frequency alarm
    Touch Panel Power button
    OLED button (ENT, ESC, UP, DOWN)
    Environment Temperature: 5°C to 40°C
    Humidity: 0 ~ 80 % R.H. (Non-condensing)
    Chassis Tower base
    Dimensions (HxWxD) 320.4 x 215 x 282.6 (mm)
    Weight 9.77Kgs
    Certificates CE/FCC/C-Tick/VCCI/BSMI
    RoHS
    WEEE

    2. Software Functions
    NAS
    RAID
    RAID Modes  RAID 0, 1, 5, 6, 10, 50 and JBOD
    Auto-rebuild Supported
    Hot-swap Supported
    Dedicated Hot Spare  Supported
    Disk
    Power Management Available spin-down on idle setting
    SMART Info Supported
    Network
    Configuration  Fixed IP address, dynamic IP address
    Transport Protocols  TCP/IP
    File Protocols  SMB/CIFS, FTP, NFS v4, DDNS, UPnP, Port forwarding
    TCP/IP IPV6 & IPV4
    Data Access
    Client OS Support  Windows XP and after
    FTP  Built-in FTP server with bandwidth control
    Data Backup
    USB device copy to V6810 Controlled through OLED
    Volume Management
    File System Selectable  XFS
    User Authentication
    Local User  Supports built-in user accounts
    Local Group  Supports built-in user groups
    File System
    Type  Journaling File System
    Language Support  Unicode Support
    Authorization (ACL) “Read”, “write”, or “deny” privileges to individual users or groups in folders and sub-folders
    Administration
    User Interface Web-based user interface supports English, Traditional Chinese, Simplified Chinese, Japanese, Korean, French, German, Italian, Spanish, Russian, Polish, Portuguese, Turkish and Czech.
    Utility Program  MS Windows Setup Wizard
    Supports Windows XP and after
    Email Notifications Sends system messages via email to the system administrator
    Others
    User/System Module Supported
    Local Display HDMI output
    UPS Supported

    Surveillance (Depending on customers' needs)

    Functionality Core Basic Extended  Enterprise
    Max. nr. of Interconnected Servers 1 1 3 Unlimited
    Max. nr. of Users per installation 3 10 20 Unlimited
    Video formats (MJPEG, MPEG-4, MxPEG, H.264) Yes Yes Yes Yes
    Export (AVI, JPEG, SAFE) Yes Yes Yes Yes
    Multi Monitor Yes Yes Yes Yes
    Remote access Yes Yes Yes Yes
    Browser access Yes Yes Yes Yes
    Event Management System (EMS) Yes Yes Yes Yes
    PTZ control Yes Yes Yes Yes
    Notification (Email, Alarmbild) Yes Yes Yes Yes
    Motion Detection Yes Yes Yes Yes
    Smart Phone Client (iPhone) - per user Optional Optional Optional Optional
    LNT (Layout Navigation Tool) - per user n/a Optional Optional Optional
    Sabotage Detection - per camera n/a Optional Optional Yes
    ABS (Adaptive Balanced Streaming) - per camera n/a Optional Optional Yes
    Encryption - per camera n/a n/a  Optional Optional
    iCAT (Video Analytics) - per camera n/a Optional Optional Optional
    Retail POS monitor - per pos n/a n/a  Optional Optional
    Active Directory - per server n/a n/a  Optional Yes
    Archive Encryption - per server n/a n/a  Optional Optional
    Number Plate recognition CarReader - per NPR camera n/a n/a  Optional Optional
    SNAP XML interface - per application n/a n/a  Optional Optional
    Retail Pegasus convention rate monitor - per project n/a n/a  Optional Optional
